HPE H3C JD103A Compatible 1000BASE-EZX SFP 1550nm 100km Transceiver Module

Product No :82704
US$ 29.90  US$ 37.38
Compatible
Transceivers type
2000 in stock
Free Shipping via UPS over $99, delivered in 5 business days in the U.S.
1. Connector: Duplex LC; with DDM
2. Low Power Consumption <1W
3. Ideal for Campus network, Metro network, Long-Haul etc
4. Hot Pluggable SFP MSA Compliant
See more +

Specifications

HPE H3C JD103A Compatible 1000BASE-EZX SFP 1550nm 100km Transceiver Module

The HPE H3C JD103A Compatible SFP optical transceiver module is equipped with an LC duplex connector, which is high-performance, cost-effective, supporting data-rate of 1.25Gbps and 100km transmission distance with SMF. This Compatible 1000BASE-EZX fiber optic transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA), and an MCU control unit. All QSFPTEK manufactured 1G SFP optical transceivers satisfy class I laser safety requirements.



Part Number: SFP-1G-EZXVendor Name: QSFPTEK
Form Factor: SFPData Rate: 1.25Gbps
Wavelength: 1550nmDistance: 100km
Connector: LC DuplexCable Type: OS2 SMF
Transmitter: DFBReceiver Type: PIN
TX Power: 0 ~5dBmReceiver Sensitivity: <-32dBm
Power Consumption: <1WModulation Format: NRZ
DDM: SupportBit Error Ratio (BER): 1E-12
ProtocolsSFF-8472 MSA Compliant, IEEE 802.3ah-2004Warranty: 3 Years

Features

  • 1. High Reliablility and Best Price
    Proudly self-producing and rigorous testing, QSFPTEK is dedicated to delivering cost-effective products with high reliability and performance at trade price.
  • 2.Convenient and Flexible Use, Easy to Install, Plug and Play.
  • 3.EMC Support, Anti Electro-Static Discharge and Radiation Resistant.
  • 4. Quality Certifications
    Backed by CE, FCC, ROSH, ISO9001.
1. High Reliablility and Best Price
Proudly self-producing and rigorous testing, QSFPTEK is dedicated to delivering cost-effective products with high reliability and performance at trade price.
2.Convenient and Flexible Use, Easy to Install, Plug and Play.
3.EMC Support, Anti Electro-Static Discharge and Radiation Resistant.
4. Quality Certifications
Backed by CE, FCC, ROSH, ISO9001.
