10ft (3m) Cat6a Network Ethernet Patch Cable Snagless Unshielded (UTP), PVC CM, Blue

Product No :100640

US$ 5.00 ~~US$ 8.00~~

Types

Cat6a

Length

1.5ft (0.45m) 3ft (0.9m) 7ft (2.1m) 10ft (3m)

50 in stock

Bulk Order Quotes Shop Online

1. Support PoE/PoE+/PoE++ (IEEE 802.3af/at/bt) and Reach Speeds up to 550MHz with 10G-T Capabilities
2. Surpasses ANSI/TIA-568-D.2 Category 6A and ISO 11801 Class E Standards for High-quality Performance
3. Tested for Performance Using Fluke and Wired T568B Methods
4. SFTP cable reduces the impact of EMI and RFI interference
5. Strain Relief and a Flexible Boot for Easy Moves, Additions, and Changes
6. Made with Stranded Cable and RJ45 Modular Plugs That Have 50μ'' Gold-plated Contacts
7. Application for Patch Panel or Equipment Connections in Enterprise Networks and Data Centers
8. Compatible with Current and Future Category 6a/6/5e/5 Applications

Specifications

Cat6a Ethernet Network Patch Cable Snagless Shielded (SFTP), 26AWG, 10GBASE-T

The Cat6a SFTP patch cable is equipped with 26AWG stranded copper cable twisted in an unshielded pair, with a high-performance modular plug at both ends. Its snagless design safeguards the RJ45 connectors' locking clips from any harm or breakage during installation. This cable surpasses the Cat6a Ethernet network cable standard, providing a cost-effective solution for indoor Gigabit Ethernet data center applications, and it supports up to 10Gbps and 550MHz within 100 meters of cable.

Cable Type	Cat6a Snagless	Shielding Type	Shielded (SFTP)
Cable Outer Jacket	PVC CM (Round)	Length	10ft (3m) (Including Plugs)
Data Rate	10GBASE-T	Maximum (Tested) Frequency	550MHz
Conductor Type	Stranded Pure Bare Copper	Conductor Type	Stranded
Max Transmission Distance	100m	Twisted Pairs	4 Pairs
Gauge (AWG)	26 (7/0.20mm)	Cable Outer Diameter	6.2mm ± 0.3mm
PoE Compatibility	PoE/PoE+/PoE++	Wire Scheme	T568B, Straight
Operating Temperature	-20 to +75°C	Installation Temperature	-10 to +50°C

Quality Certifications

Features

Applications

Scenario 1

Scenario 2

Scenario 3

Product details

High-Bandwidth Transmission

Supports a maximum bandwidth of 550MHz at 10Gbps, making it ideal for Fast Ethernet, Gigabit Ethernet, and 10-Gigabit Ethernet.

transceiver compatibility tests

Multiple Shielded Ethernet Cabling

The cable is easy to plug, and well-protected with an RJ45 modular plug and PVC jacket, which greatly improves the service life of the cable, making it highly compatible with routers, switch boxes, network printers, and other devices.
