Connector: Duplex LC; with DDM Low Power Consumption <1W Ideal for Campus network, Metro network, Long-Haul etc Compatible with 200+ Vendors Hot Pluggable SFP MSA CompliantSee more
The Brocade 10G-SFPP-BXU-60K compatible SFP+ optical transceiver is equipped with an LC simplex connector, reaching a link up to 60km over G.652. This 10G BiDi SFP+ transceiver, featured with carrying information in both directions via a single strand, can double your network capacity and save your cable resources. QSFPTEK manufactured 10GBASE-BX BiDi SFP+ transceiver module is compliant with SFP+ MSA, IEEE 802.3ae, SFF-8431. Besides, DDM (digital diagnostics monitoring) function is supported on the 10G fiber optic transceiver to achieve real-time operating parameters monitoring. It's also fully compatible with almost all Cisco devices.
Model Name: |
SFP-10G-BX60U |
Vendor Name: |
QSFPTEK |
Form Factor: |
SFP+ |
Data Rate: |
10Gbps |
Wavelength: |
1270nm-TX/1330nm-RX |
Distance: |
60km |
Connector: |
LC Simplex |
Cable Type: |
OS2 SMF |
Transmitter Type: |
DFB |
Receiver Type: |
PIN |
TX Power: |
1~5dBm |
Receiver Sensitivity: |
<-21dBm |
Power Consumption: |
<0.8W |
Modulation Format: |
NRZ |
DDM: |
Support |
Bit Error Ratio (BER): |
1E-12 |
Protocols: |
Fast Ethernet, Gigabit Fibre Channel, MSA Compliant |
Warranty: |
5 Years |
Connection 1: 10G BIDI Connectivity
Related Products:
S5300-48T4X, 48-Port Gigabit Ethernet L2+ Switch, 48 xGE RJ45, with 4 x10GE SFP+, Support Stacking
LC UPC to LC UPC Simplex OS2 2.0mm PVC Fiber Optic Patch Cable 3m
S5300-48T6X, 48-Port Gigabit Ethernet L3 Switch, 48 xGE RJ45, with 6 x10GE SFP+, Support Stacking
Connection 2: 10G BIDI Connectivity With NIC
Related Products:
LC UPC to LC UPC Duplex OS2 2.0mm PVC Fiber Optic Patch Cable 3m
Intel X710-BM2 Network Interface Card, 10G 2 × SFP+ Port , PCIe 3.0 X 8, Half & Full Bracket
BiDi SFP+ module allows data transmitting and receiving over one single fiber, greatly saving network fiber resources and costs.
Every module is quality tested for compatibility in the multi-brand switches environment, which guarantees flawless operations.
Every unit sold undergoes rigorous quality testing, to ensure compatibility in the target switch environment, guaranteeing perfect operation.
Every module is qualified through rigorous procedures and advanced equipment to ensure high-quality and reliable optical devices for you.
