Cisco C21 DWDM-SFP10G-60.61 Compatible 10G DWDM SFP+ 1560.61nm 80km DDM LC SMF Transceiver

Product No :99136

US$ 109.00 ~~US$ 139.99~~

Specifications

Cisco C21 DWDM-SFP10G-60.61 Compatible 10G DWDM SFP+ Optical Transceiver Module (SMF, 1560.61nm, 80km, LC, DDM)

The Cisco C21 DWDM-SFP10G-60.61 compatible DWDM-SFP10G-80 series 10G SFP+ transceiver module is equipped with an LC duplex connector, reaching a link up to 80km over G.652/655 single-mode fiber (SMF). This 10G DWDM SFP+ transceiver operates at a nominal DWDM wavelength at C21 channel - 1560.61nm as specified by the ITU-T, designed for DWDM networking equipment connectivity.

QSFPTEK manufactured 10GBASE-DWDM SFP+ module is compliant with the SFF-8431 MSA and SFF8432 MSA specifications. Besides, the small form-factor pluggable plus (SFP plus) optic has been tested on host devices to ensure full compatibility with Cisco equipment, such as Ethernet switches, enterprise routers, and server network interface cards (NICs). The third-party DWDM 10G SFP module is an ideal substitute to the Cisco C21 DWDM-SFP10G-60.61 SFP+ 10G transceiver at an affordable price, providing a cost-effective compatible solution for high-performance 10G connectivity.

DWDM 10G SFP+ optics cater to 10 Gigabit Ethernet (10GbE) optical fiber connections, ideal to be deployed for Long Haul DWDM Solution in metropolitan access and core networks.

Model Name	C21 DWDM-SFP10G-60.61	Vendor Name	QSFPTEK
Form Factor	SFP+	Data Rate	9.95 to 11.3Gb/s bit rates
Wavelength	1560.61nm	Distance	80km@G.652
Connector	LC Duplex	Cable Type	OS2 SMF
Transmitter Type	EML	Receiver Type	APD
TX Power	0~+5dBm	Receiver Sensitivity	<-24dBm
Power Consumption	<1.5W	Modulation Format	NRZ
DDM	Support	Bit Error Ratio (BER)	1E-12
Protocols	IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432	Warranty	3 Years

Quality Certifications

Features

1. High Reliablility and Best Price

Proudly self-producing and rigorous testing, QSFPTEK is dedicated to delivering cost-effective products with high reliability and performance at trade price.
2. Wide Application Scenarios

Deploy in the DWDM networking equipment in metropolitan access and core networks.
3. Protocols

Compliant with IEEE 802.3ae, SFF-8431 MSA, SFF8432 MSA.
4. Quality Certifications

Backed by CE, FCC, ROSH, ISO9001.

Applications

1. Plug 10G DWDM SFP+ optics into 10GbE switch ports for 10 Gigabit Ethernet (10GbE) connectivity in data center high-density solution

Product details

Every module is quality tested for compatibility in the multi-brand switches environment, which guarantees flawless operations.

Questions & Answers

more+

Passive DWDM SFP+ and CWDM SFP+, which to choose?

Both DWDM and CWDM technology are wavelength-division multiplexing which combines a number of optical links on the same physical fiber using different colors (or wavelengths) of laser light. They have a major difference – the spectral width of channels. CWDM channel width is 20nm, accordingly, DWDM 100GHz is 0.8nm. DWDM has advantages from aspects of channel spectral width, channel uniformity aspect, and capacity. In the technical battle of CWDM vs DWDM, more advancements are in DWDM. QSFPTEK tech team will provide free solution recommendations according to your practical application. Please feel free to contact us.

Customer Reviews

Write a Review

Total score

(8 Reviews)

5 stars

8 Reviews

4 stars

0 Reviews

3 stars

0 Reviews

2 stars

0 Reviews

1 stars

0 Reviews

Oswald Tuttle United States of America

2022-12-28

The product was received quickly, the quality is very good, the account manager responded quickly, and I got a very good shopping experience~

Transceivers typeC36 DWDM-SFP10G-48.51

CompatibleCisco

0

0

Submit
Luther Snow United States of America

2022-12-07

It is used with the switch, it works very well on my new machine, by the way, I recommend the cable management rack, it is very convenient.

Transceivers typeC36 DWDM-SFP10G-48.51

CompatibleCisco

0

0

Submit
Antonia K United States of America

2022-12-01

The product is great, it is very compatible with my cisco switch, and I am going to buy another one as a gift to a friend.

Transceivers typeC36 DWDM-SFP10G-48.51

CompatibleCisco

0

0

Submit
LYONS United States of America

2022-11-21

We purchased a complete 860 series solution for our DWDM P to P solution. It took about 2 months because our planning was complicated. But the whole ordering process was great. According to their suggestion, we have carried on some modification of the original plan to this DWDM network. Sales and technical support always provide satisfactory solutions. Our transmission distance reaches 120km because we have to calculate dispersion and power. We use Cisco network switches and these modules work great with our switches and DWDM MUX/DEMUX. The total cost was well below our expectations, and the transfer quality was solid. We are very satisfied with this purchase.

Transceivers typeC60 DWDM-SFP10G-29.55

CompatibleCisco

0

0

Submit
Paddy Joan United States of America

2022-10-27

Easy to find the wanted transceiver. Great price and easy check out. We'll see how the shipment goes.

Transceivers typeC60 DWDM-SFP10G-29.55

CompatibleCisco

0

0

Submit
Larry Pressnell United States of America

2022-09-29

We using Cisco 4500 switch. At first we are going to order original cisco modules. However, we found this website provide third party modules. And it is really cheap. So we bought several fiber patch cables and one of this module to see how it works. No Compatible problem at all. Now we have already ordered more.

Transceivers typeC21 DWDM-SFP10G-60.61

CompatibleCisco

0

0

Submit
Ahusaka Winnebago United States of America

2022-03-31

This SFP+ DWDM transceiver module is successfully used in our data center. Before that, we learned how to use SFP+ DWDM to build 80km transmission through the QSFPTEK Blog, and we used a preamplifier, output booster. With these auxiliary devices, we successfully set up an 80km point-to-point DWDM system in our data center.

Transceivers typeC22 DWDM-SFP10G-59.79

CompatibleCisco

0

0

Submit
T H Kuwait

2021-10-19

In order to build 200G connection between 2 places in Kuwait City. We need a cost-effective WDM solution, then i turn to QT for help. They offer me a good solution with 40ch mux and 10g 40km dwdm modules which has low cost and superior performance. I'm satisfied.

Transceivers typeC21 DWDM-SFP10G-60.61

CompatibleCisco

0

0

Submit

Datasheet

DWDM-SFP+-ZR-XX.pdf
