Cisco QDD-400G-DR4-S Compatible 400GBASE-DR4 QSFP-DD PAM4 1310nm 500m DOM MTP/MPO SMF Optical Transceiver Module

Product No :99912
US$ 749.90  US$ 999.00
Compatible
2000 in stock
Free Shipping over US$ 84.9. US/EU Warehouses in stock, Overnight Shipping
1. PAM4 modulation technology
2. EML + PIN, MTP/MPO-12 connector
3. Low power consumption < 10W
4. 8x 53.125Gb/s 400GAUI-8 electrical interface
5. Parallel 4 optical lanes, support 4x 100G breakout to QSFP28 100G-DR, 100G-FR, and 100G-LR
6. Applied in 400G Ethernet, Infiniband interconnects, data centers, high-performance computing networks
See more

Specifications

Cisco QDD-400G-DR4-S Compatible 400GBASE-DR4 QSFP-DD PAM4 Optical Transceiver Module (SMF, 1310nm, 500m, MTP/MPO, DOM)



400GBASE-DR4 QSFP-DD transceiver is designed for 400G Ethernet interconnection, allowing link up length up to 500m over single-mode fiber (SMF) with MTP/MPO connector. It is compliant with the QSFP-DD MSA, IEEE 802.3bs standard. The 400GBASE DR4 module converts 8 channels of 50Gb/s (PAM4) electrical signals into four parallel lanes of optical signals, each lane capable of 100Gb/s. It supports 4x100G breakout to QSFP28 100G-DR, 100G-FR, and 100G-LR transceivers. Utilizing PAM4 modulation technology, 400GBASE-DR4 provides a cost-effective and low power consumption solution for 400G Ethernet applications, data centers, Infiniband interconnects, and high-performance computing networks.



Part Number

QT-QSFP-DD-DR4

Vendor Name

QSFPTEK

Form Factor

QSFP-DD

Interface Type

DR4

Max Data Rate

425Gbps (4x106.25Gb/s)

Wavelength

1310nm

Connector

MTP/MPO-12

Cable Type

SMF

Max Cable Distance

500m

Modulation

PAM4

TX Power

-2.9~4.0dBm

Receiver Sensitivity

< -5.9dBm

Transmitter Type

EML

Receiver Type

PIN

Power Consumption

< 10W

Temperature Range

0 to 70°C (32 to 158°F)

DDM/DOM

Supported

Forward Error Correction (FEC)

Host FEC Supported

Protocols

QSFP-DD MSA, IEEE 802.3bs

Warranty

2 Years



Quality Certifications

Features

  • 1. High Density and Best Price
    Proudly self-producing and rigorous testing, QSFPTEK is dedicated to delivering cost-effective products with high reliability and performance at a trade price.
  • 2. Wide Application Scenarios
    Fully compatible with almost all Cisco devices. Ideal for data centers, campus network, enterprise core layer, etc.
  • 3. Protocols
    Compliant with QSFP-DD MSA, IEEE 802.3bs.
  • 4. Quality Certifications
    Backed by CE, FCC, ROSH, ISO9001.

Applications

Product details

Various Switch Tests



Every module is quality tested for compatibility in the multi-brand switches environment, which guarantees flawless operations.



transceiver compatibility tests






Tested in The Host Device to Prove Interoperability



Every unit sold undergoes rigorous quality testing, to ensure compatibility in the target switch environment, guaranteeing perfect operation.








Comprehensive Testing



Every module is qualified through rigorous procedures and advanced equipment to ensure high-quality and reliable optical devices for you.





Questions & Answers

more+
  • What is the difference between using 4x100 vs 8x50 of 400G QSFP-DD transceivers?
    The main difference is that the optical signal transmission method, 4x100G means transmitting optic signals in 4 channels, and 100G each channel, while 8x50G is transmitted optic signal in 8 channels, and 50G each channel.
  • What's the meaning of ''DR4''?
    ''DR'' means that the 500m transmission distance and using Singlemode fiber, ''4'' implies there refers to 4 optical channels. The 4 independent optical channels inside the DR4 modules transmitting data on separate fibers make up a total of 8 fibers(4 Tx and 4 Rx). Each of the optical channel transmission rates is 100Gb/s.
